Flat Suction Cups SAOF (Oval)

Suction area (LxW) from 50 x 16 mm to 140 x 70 mm

Go directly to the products

Wide range of diameters for a large selection of different workpieces

Large, structured inner support prevents deformation and withstands the highest lateral forces even on oily sheets

Flat suction cups in oval design for long workpieces (profiles, pipes) or flat workpieces with webs

Soft, flexible sealing lip seals optimally

Design

Robust and wear-resistant oval suction cup SAOF made of NBR with single sealing lip, special slot and inner support
Connection nipple glued to the reinforcing element of the suction cup (very high strength)
Suction cups available with various connection types
Available in two material hardness values (45 Shore, 60 Shore)

Technical Data

Dimensions: 50 x 16 to 140 x 70 mm
Material: NBR
Connection nipple vulcanized to elastomer part

Documentation

The matching documentation for this product is available in this section.

Documents	Language
Product family overview	English

1 - 10 from 86 results

SAOF 50x16 NBR-45 G1/4-AG

Part no.: 10.01.05.00550

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	45 (Shore A)
Nipple material	Aluminum
Connection	G1/4-AG

SAOF 50x16 NBR-60 G1/4-AG

Part no.: 10.01.05.00521

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	60 (Shore A)
Nipple material	Aluminum
Connection	G1/4-AG

SAOF 50x16 NBR-60 G1/4-IG

Part no.: 10.01.05.00511

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	60 (Shore A)
Nipple material	Nickel plated
Connection	G1/4-IG

SAOF 50x16 NBR-45 G1/4-IG

Part no.: 10.01.05.00551

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	45 (Shore A)
Nipple material	Nickel plated
Connection	G1/4-IG

SAOF 50x16 NBR-60 G3/8-IG

Part no.: 10.01.05.00518

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	60 (Shore A)
Nipple material	Nickel plated
Connection	G3/8-IG

SAOF 50x16 NBR-45 G3/8-IG

Part no.: 10.01.05.00553

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	45 (Shore A)
Nipple material	Nickel plated
Connection	G3/8-IG

SAOF 50x16 NBR-45 M10-AG

Part no.: 10.01.05.00555

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	45 (Shore A)
Nipple material	Steel
Connection	M10-AG

SAOF 50x16 NBR-60 M10-AG

Part no.: 10.01.05.00527

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	60 (Shore A)
Nipple material	Steel
Connection	M10-AG

SAOF 50x16 NBR-60 M14x1.5-AG

Part no.: 10.01.05.00530

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	60 (Shore A)
Nipple material	Aluminum
Connection	M14x1.5-AG

SAOF 50x16 NBR-60 RA

Part no.: 10.01.05.00515

Flat suction cup (oval) for very dynamic handling of smooth and oily workpieces

Dimension (LxW)	50x16
Suction cup material	Nitrile rubber NBR
Material hardness [Shore A]	60 (Shore A)
Nipple material	Aluminum
Connection	RA
