| Internal diameter d | 105 (mm) |
| Length L | 18 (mm) |
| Material | Nitrile rubber NBR |
Spare and Wear Parts Vacuum Tube Lifters JumboErgo / Jumbo Sprint
Design
Design
- Vacuum generation, lifting hoses, protective hoses, etc
Technical Data
Technical Data
- Wide range of spare and wear parts
- Vacuum generation, lifting hoses, protective hoses, etc
1 - 10 from 301 results
| Internal diameter d | 63 (mm) |
| Length L | 13 (mm) |
| Material | Nitrile rubber NBR |
FLK G1/2-IG G1/2-AG
Part no.: 10.01.03.00175
Flexible suction cup mounting for adaptation to sloping surfaces
| Thread G1 | G1/2"-F |
| Thread G2 | G1/2"-M |
| Operating temperature | 0 ... 70 °C |
| Outside diameter D | 41 (mm) |
| Internal diameter d | 35 (mm) |
| Length max. | 50 (m) |
| Material hose | PVC with PVC-spiral |
| Bending radius min. | 65 (mm) |
| Pressure range (operating pressure) [bar] | -0.50 ... 0.50 bar |
| Operating temperature | -20 ... 70 °C |
| Color | grey |
| Clamping range [mm] | 35.0 ... 40.0 mm |
| Material | Steel |
| Surface | galvanised |
| Clamping range [mm] | 28.0 ... 32.0 mm |
| Material | Steel |
| Surface | galvanised |
| for | G1 |
| Outside diameter D | 39 (mm) |
| Internal diameter d | 34 (mm) |
| Material | Polyamide |
SBM-160-520-IE3-TYP4
Part no.: 11.02.05.10155
Directly driven vacuum blower for tube lifter applications
| Sound pressure level at 50 Hz | 70.5 (dB(A)) |
| Voltage at 50 Hz | D290 V / Y500 V ±10 % |
| Voltage at 60 Hz | D330 V / Y575 V ±10 % |
| Suction rate (50 Hz) | 160 (m³/h) |
| Suction rate (60 Hz) | 190 (m³/h) |
| Rated power at 50 Hz | 3 (kW) |
| Rated power at 60 Hz | 3.6 (kW) |
| Version | IE3:CAN |
| Approval | UL/CSA |
| Weight | 43 (kg) |
| Category | Electrical vacuum generation |
