Part no.: 10.01.05.01059
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 75x25 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | G1/4"-F |
Flat suction cups in oval design for long workpieces (profiles, pipes) or flat workpieces with webs
Two-ear clamp prevents unintentional twisting during use (from size 24 x 8 mm)
High suction force with small dimensions
Support surfaces on the bottom prevent permanent deformation of thin-walled workpieces
Design
Design
- Robust, wear-resistant suction cup SGON (3) with single sealing lip, consisting of suction cup SGO (2) and connection nipple (1)
- Nipple plugged into cup
- From size 24 x 8 mm, the suction cup is additionally secured with a two-ear clamp (anti-rotation device)
- With each nipple family, the replacement cups and nipples can be combined as desired
Technical Data
Technical Data
- Dimensions: 4 x 2 to 90 x 30 mm
- Material: HT1, NBR, NBR-ESD, NBR-CO, SI, SI-HD
- Additional anti-rotation device from size 24 x 8 mm
Documentation
Documentation
The matching documentation for this product is available in this section.
| Documents | Language |
|---|---|
| English |
1 - 10 from 20 results
Part no.: 10.01.05.01055
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 45x15 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | G1/4"-F |
Part no.: 10.01.05.01056
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 45x15 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | G1/4"-M |
Part no.: 10.01.05.01053
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 30x10 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | G1/8"-F |
Part no.: 10.01.05.01052
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 24x8 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | G1/8"-M |
Part no.: 10.01.05.01054
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 30x10 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | G1/8"-M |
Part no.: 10.01.05.01047
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 15x5 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | M5-F |
Part no.: 10.01.05.01051
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 24x8 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | G1/8"-F |
Part no.: 10.01.05.01048
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 15x5 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | M5-M |
Part no.: 10.01.05.01060
Flat suction cup (oval) for long and also curved workpieces
| Dimension (LxW) | 75x25 |
| Suction cup material | Silicone SI-HD |
| Material hardness [Shore A] | 65 (Shore A) |
| Nipple material | Aluminum |
| Connection | G1/4"-M |
