| Clamping range [mm] | 11.0 ... 13.0 mm |
| Material | Galvanized steel |
Spare and Wear Parts VacuMaster Glass
Design
Design
- Vacuum generators, filters, valves, drives, measuring equipment, suction plates and connections
Technical Data
Technical Data
- Wide range of spare and wear parts
1 - 10 from 34 results
| Clamping range [mm] | 15.0 ... 18.0 mm |
| Material | Galvanized steel |
| Connection | Hose 8/6 with Cap nut |
| Filter pore size | 50 (µm) |
| Outside diameter D | 4 (mm) |
| Internal diameter d | 2 (mm) |
| Length max. | 50 (m) |
| Material hose | PU |
| Bending radius min. | 20 (mm) |
| Pressure range (operating pressure) [bar] | -0.95 ... 10.00 bar |
| Operating temperature | -40 ... 60 °C |
| Color | Milky-transparent |
| Thread G1 | G1/4"-M |
| Outer hose diameter | 8 (mm) |
| Material | Brass |
| Operating temperature | -20 ... 80 °C |
| Outside diameter D | 13.9 (mm) |
| Length L | 17.8 (mm) |
| Thread G1 | G1/2"-M |
| Material | Brass |
| Surface | nickel plated |
SPIR-SCHL 8-5 PU
Part no.: 10.07.09.00100
Spiral hose for flexible length compensation in vacuum and compressed-air lines
SPIR-SCHL 8-5 PU
Part no.: 10.07.09.00099
Spiral hose for flexible length compensation in vacuum and compressed-air lines
