Chocolate Suction Cups SPG
- Diameter: 33 mm
- Material: SI, SI-HD (use in the food industry)
Show category
Automated solutions for hygienic areas
Automated solutions for hygienic areas
Customized automation solutions for hygiene and production processes
This page provides you with an excerpt from our diverse Vacuum Automation portfolio. Discover our comprehensive product portfolio from vacuum generators to mounting elements and suction cups in a personal consultation – we develop the customized design of your vacuum system together with you, precisely tailored to your processes and hygiene requirements.
Vacuum suction cups
The materials used are FDA-compliant and comply with EC Regulation No. 1935/2004 to avoid contamination.
Schmalz suction cups made from the materials SI, SI-HD and SI-MD are suitable for handling in hygienic areas. This material composition allows, among other things, direct contact with food products.
Bellows Suction Cups FSDC
- Diameter: 40 mm
- Material: SI-HD, SI-MD
Show category
Bellows Suction Cups (Round)
- Handling of uneven and curved workpieces
- Suction bellows for height compensation
- Damping effect for sensitive workpieces
Show category
Bellows Suction Cups (Round)
- Handling of uneven and curved workpieces
- Suction bellows for height compensation
- Damping effect for sensitive workpieces
Show category
- NEW
Bin-Picking Suction Cups SVE
- Diameter: 33 mm and 53 mm
- Material: PU, SI-MD (use in the food industry)
Show category
Flat Suction Cups (Round)
- Handling of flat workpieces
- Low internal volume
- Fast and precise gripping
Show category
Flat Suction Cups SGON
- Dimensions: 4 x 2 to 90 x 30 mm
- Material: HT1, HT1-ESD, NBR, NBR-ESD, NBR-CO, SI, SI-HD
- Additional anti-rotation device from size 24 x 8 mm
Show category
Special grippers
The hygienic design and easy disassembly of our special grippers make them easy to clean. The finger gripper mGrip from Schmalz takes ease of cleaning to a new level: the closed system can be cleaned completely without disassembly. Stainless steel and FDA-compliant materials prevent contamination and ensure safe handling.
Suction Cups for Flow Grippers SFG
- Diameter suction area: 60 mm, suction cup: 20 mm to 50 mm
- Suction areas made of FDA compliant POM
- Suction cups made of silicone (SI-HD / SI-MD) (FDA compliant)
Show category
- NEW
Finger Grippers mGrip
- Load capacity up to 10 kg
- Workpiece width up to 300 mm
- Gripping speed up to 120 picks per minute
- Gripper made of FDA-compliant materials (POM, silicone, stainless steel), protection class IP69K
Show category
Flow Grippers for Food SFG
- Suction rate: 270 l/min to 650 l/min
- Suction cup made from FDA compliant silicone
- Diameter contact element: 20 to 60 mm
Show category
Feed Ejectors SEC
- Suction capacity up to 8,640 l/min
- Diameter: 6 to 75 mm
Show category
Mounting elements
Ease of cleaning is ensured by the stainless steel connection nipples.
| Nipple family | N 016 |
| Thread G1 | G1/8"-M |
| Length L1 | 20 (mm) |
| Fitting length | 6 (mm) |
| Nominal diameter dn | 3.1 (mm) |
| 3 (mm) | |
| Material | Austenitic stainless steel |
| Nipple family | N 016 |
| Thread G1 | G1/8"-F |
| Length L1 | 18.5 (mm) |
| Fitting length | 12 (mm) |
| Nominal diameter dn | 3.1 (mm) |
| Material | Austenitic stainless steel |
| Nipple family | N 016 |
| Thread G1 | M5-M |
| Length L1 | 16 (mm) |
| Fitting length | 5 (mm) |
| Nominal diameter dn | 2.5 (mm) |
| 3 (mm) | |
| Material | Austenitic stainless steel |
| Nipple family | N 016 |
| Thread G1 | M5-F |
| Length L1 | 16 (mm) |
| Fitting length | 10 (mm) |
| Nominal diameter dn | 3.1 (mm) |
| 3 (mm) | |
| Material | Austenitic stainless steel |
Inquire about an individual solution
Contact us for a comprehensive consultation – we will configure a tailored solution together with you to meet your hygienic requirements.
